ABLIC offers ICs best for Power Closure Systems. ABLIC offers a comprehensive range of products: such as high-accuracy operational amplifiers that detect pinching prevention, LDOs with built-in watchdog timers to monitor MCUs, LDOs and Voltage Trackers developed for sensor power supplies, and ZCL™ Hall effect ICs which operate optimally in BLDC motors.

Watchdog Timer:

S-1951x——With reset and LDO regulator functions. Current consumption of 3.0μA.

Voltage Tracker:

S-19720——The industry’s lowest offset voltage of ±5mV. Available in an ultra compact (2.46 x 1.96mm) package. Current consumption during power-off of 4μA.

LDO Regulator:

S-19212——Powers the sensor. The output voltage can be set between 2.5 to 16V.

Hall effect IC:

S-57TZ S——ZCL™ Hall effect ICs are perfect for BLDC motor control, creating stable BLDC motor control over a wide temperature range.

Operational amplifier:

S-19630A——High-accuracy current detection. 36V operation, Rail-to-Rail input/output, low offset voltage of 50μV.

EEPROM:

S-93CxxC H (3-wire)、S-24CxxC H (2-wire)、S-25CxxxA H (SPI)——Serial EEPROM. Built-in data protection functions. 105°C max. operation.
